| 温度の特徴: | +85°C △C/C≤30%,ESR≤25°C) -40°C △C/C≤30%,ESR≤4 (25°C) | ESR: | DC @25°C,≤1500 MΩ AC 1kHz@25°C ≤240 MΩ |
|---|---|---|---|
| 72時間 漏れ流量 25°C: | 6 μA | 高温負荷: | +85°C≤2.7V,1000h,△C/C≤30%,ESR≤4 |
| 定格電圧: | 2.7V | 動作温度: | -40~ +85 °C @2.7V |
| カスタマイズ: | サンプル サービスを提供しなさい | サージ電圧: | 2.85V |
| ハイライト: | 2.7V 3.3F super capacitor,automotive start-stop super capacitor,2.7V super capacitor for cars |
||
This advanced Super Capacitor delivers exceptional performance and reliability across diverse applications. Engineered with precision, this high-capacity capacitor features a 2.7V rated voltage, making it ideal for electronic devices and systems requiring stable, efficient energy storage solutions.
With an impressively low leakage current of just 6 μA after 72 hours at 25℃, it ensures minimal energy loss and long-term efficiency. The capacitor operates reliably within a broad temperature range from -40℃ to +85℃, making it suitable for automotive, industrial, and consumer electronics applications.
| Nominal Capacity | 1.0F |
| Peak Current | 0.54A |
| Operating Temperature | -40℃ to +85℃ @ 2.7V |
| ESR (DC @25℃) | ≤1500 MΩ |
| ESR (AC 1kHz @25℃) | ≤240 MΩ |
| Leakage Current | 6 μA (@25℃, 72 hours) |
| Surge Voltage | 2.85V |
This high-capacity capacitor is ideal for automotive electronics, renewable energy systems, industrial equipment, backup power supplies, memory retention systems, and portable electronic devices including cameras, handheld devices, and wearable technology.
We provide comprehensive customization options including sample services, technical support, product documentation, and warranty coverage. Our technical team offers expert advice on product selection, circuit design, and troubleshooting.
Each unit is individually wrapped in anti-static material with foam cushioning, placed in sturdy double-walled cardboard boxes. Multiple shipping options available with tracking and insurance.
